Enhanced first pass efficiency with MAPSS™ technology
HIGHLY DISCRIMINATE, SEQUENTIAL SEPARATION USING MAPSSTM TECHNOLOGY
MAPSS™ (MULTI-ANGLE POLARIZED SCATTER SEPARATION) TECHNOLOGY PROVIDES LASER-ACCURATE OPTICAL READINGS FOR WBCs AND DIFFERENTIALS
- Axial Light Loss (ALL) provides total count and size of each cell
- Intermediate Angle Scatter (IAS) indicates complexity of intracellular structure
- Polarized Side Scatter (PSS) provides details on granularity and nuclear lobularity, separating mononuclear from polymorphonuclear cells
- Depolarized Side Scatter (DSS) separates neutrophils from eosinophils
Two-dimensional Optical Platelet (PLT) Analysis
Reportable platelet counts across a wide variety of abnormal conditions
- First Pass two-angle analysis separates the PLT and RBC populations
- Reduces interference from microcytic RBCs, schistocytes and non-platelet particles
- Obtain reportable results in the presence of giant or clumped PLTs and on thrombocytopenic samples without reflexing or extra reagents
Three-dimensional Optical Red Blood Cell (RBC) Analysis
Improves the accuracy of red cell measurement, including reticulocytes
- Comprehensive cell-by-cell measurements with readings taken at 0º, 10º and 90º by light scatter detectors enable exquisite accuracy of RBCs and reticulocytes
- Reticulocyte assay based upon NCCLS/ICSH methods
Four-dimensional White Blood Cells (WBC) Analysis
WBCs are counted and classified so that results can be reported on the first run, even when abnormal cells and interfering substances are present
- Reduce manual reviews due to interference from NRBCs, clumped platelets and debris
- MAPSS™ technology can detect potential interference from lysis-resistant RBCs; the flagged samples can be re-run in the lysis-resistant mode without microscopic review
Touch-Screen Convenience & Flexibility With Multifaceted Software
Enhance workflow efficiency with QC management, user-definable decision rules, smart software features and Abbott link
Harmonize Laboratory Data With AlinIQ AMS Middleware
Increase operational efficiency
|
DESCRIPTION
|
|
Maximum Throughput (Autoloader Mode)
|
CBC + Differential: Up to 84 per hour
|
|
Sample Volume
|
Open Mode 150 μL, Sample Loader 230 μL
|
|
Reagents
|
Only 4 reagents including reticulocytes
|
|
Technology
|
WBC and differential
|
4 angle optical MAPSS Multiple Scatterplot Analysis
|
|
Platelets
|
Dual angle optical analysis, no extra reagent, no reflex testing requirement
|
|
Reticulocytes
|
New Methylene Blue NCCLS method, supravital staining technique
|
|
Analytical Measurement Ranges
|
WBC
|
0.02–246.8 x 103/μL
|
|
RBC
|
0.00–7.50 x 106/μL
|
|
HGB
|
0.0–25.0 g/dL
|
|
HCT
|
8.3-79.8%
|
|
MCV
|
58–139 fL
|
|
RDW
|
10.0-29.8%
|
|
PLT
|
0.0–3000 x 103/μL
|
|
MPV
|
4.3-17.2 fL
|
|
RETC
|
0.2–22.9%
|
|
Data Management
|
Windows®-based operating system. Rules-based result annotations. Full on-board QC package. Levey-Jennings plots. Moving Averages. Westgard rules. 10,000 results stored with graphics. Auto calibration online guide.
|
|
System Control Center
|
A single computer with color touch-screen monitor, keyboard, and mouse
|
|
Dimensions (HxWxD)
|
- Height - 19.25 inches (49.9 cm)
- Width - 34 inches (86.4 cm)
- Depth - 30.25 inches (76.8 cm)
|
|
Weight
|
232 pounds (105.2 kilograms)
|
|
Electrical Requirements*
|
VAC 100-240V, 50/60Hz
|
|
Maximum Power Consumption*
|
550 watts
|
