FEATURE
|
ALINITY HQ
|
ALINITY HS
|
|
System Dimensions
(HxDxW)
|
149.9 cm (59 in) x 91.4 cm (36 in) x 66 cm (26 in)
|
149.9 cm (59 in) x 91.4 cm (36 in) x 76.2 cm (30 in)
|
|
System Footprint
|
0.6 m²
|
0.7 m²
|
|
Weight
|
250 kg (553 lbs)
|
281 kg (620 lbs)
|
|
Maximum Throughput
|
- 119/hr for CBC + Differential
- 70/hr for CBC + Differential + Reticulocyte
|
65 stained smears per hour*
|
|
Technology
|
- WBC and Differential – Optical Scatter and Fluorescence
- RBC – Optical Scatter and Fluorescence
- Platelet – Optical Scatter
- Reticulocytes – Optical Scatter and Fluorescence
|
Stain and smear, smear only and stain only. Custom Stain protocols can be created. The smear is performed by a single-use blade based on the hematocrit results provided by user, or determined by the integrated analyzer
|
|
Reportable Parameters
|
WBC, 6-part Differential (NEU, %NEU, LYM, %LYM, MONO, %MONO, EOS, %EOS, BASO, %BASO, IG, %IG), RBC, HGB, HCT, MCV, MCH, MCHC, RDW, NRBC, NR/W, RETIC, %R, IRF, MCHr, PLT, MPV, %rP
|
Not applicable
|
|
Reagents and Consumables
|
Ready to use: WBC Reagent, HGB Reagent, Retic Reagent, Diluent, Autoclean solution
|
Ready to use: May-Grünwald-Giemsa stain or Wrights Giemsa Stain, Phosphate buffer, Smear Fix, Glass Slides, Slide Label Cartridge, Smear Tape Cartridge
|
|
Continuous Access of Reagents and Consumables
|
Yes
|
|
Flexible STAT Options
|
Yes. Any tube lane can be designated as a STAT lane
|
|
Sample Capacity
|
120 tubes
|
80 tubes, 210 blank slides, 120 stained/smeared slides
|
|
Sample Aspiration Volume
|
- CBC+ Diff: < 100 μl
- CBC+ Diff + Retic: < 100 μl
|
<25 μl
|
|
Sample Result Storage
|
100,000 Result Records, 100 Calibration Files, 1000 QC Files
|
|
User Configurable Rules
|
Reflex and retest based on parameter limits, morphology flags, and delta checks
|
|
LAS Integration
|
Yes, ACCERLATOR a3600 for the Alinity hq-hs-hq and Alinity hq configurations
|
